Learn about Nitronic® 60, a premium Stainless Steel alloy commonly used in bearings, shafts, valves and more.
Nitronic® 60 Overview
Nitronic 60, also referred to as Alloy 218, is a stainless steel designed for excellent wear resistance and anti-galling performance. Its enhanced properties are primarily due to the addition of silicon and manganese, which help minimize wear and prevent galling under friction-intensive conditions.
Nitronic® 60 Composition
| C | Si | Mn | Ni | Kr | S | P | Mo | N | Cu | Fe | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Min % | – | 3.5 | 7 | 8 | 16 | – | – | – | 0,08 | – | Bal |
| Max % | 0.1 | 4.5 | 9 | 9 | 18 | 0,03 | 0,04 | 0,75 | 0,18 | 0,75 |
Designations and Specifications
Designations
- UNS S21800
Specifications
- AMS 5848
- ASTM A580
Anwendungen
Common Nitronic® 60 applications include:
- Valve Stems
- Pins
- Brushes
- Roller bearings
- Pump shafts and rings
- Thread inserts Fasteners
Zerreißfestigkeit
| Condition | N/mm² | KSI |
|---|---|---|
| Annealed | <1000 | <145 |
| Condition | As Drawn | |
|---|---|---|
| N/mm² | KSI | |
| Spring Temper | 1300 – 1900 | 189 – 276 |
Verpackungsoptionen
- Spulen
- Spulen
- Bars/Cut Lengths
- Kundenspezifische Verpackung verfügbar
